Medical Blue/Green Sensitive X-Ray film
This film uses the latest T-grain technology, it has high photographic sensitivity, forgiving exposure tolerance latitude, low fog-density, high contrast , high visibility of details and rich information. Under the same image quality conditions, this film greatly reducing the harm of rays. With bluish polyester base (blue image tone) and T-grain technology, it delivers excellent viewing characteristics, it makes the image of high sharpness, good resolution and rich image details, improved the image contrast and practical clarity.
Categories：
Medical Blue Green Sensitive X-Ray Film
Green sensitive X ray film kind of general purpose conventional medical x-ray film, double side coated on PET-base, medium~high contrast film and suitable for all types of radio-graphic examinations.This film is used for the examination of human body disease and abnormal changes of viscera, bones and soft tissues, providing reliable information for clinical diagnosis. This film is designed for use with rare earth intensifying screens. It features high speed, low gross fog, wide exposure latitude, excellent contrast and high detail sharpness.
Product Paramenters
Excellent performance of photographic properties:
This film uses the latest T-grain technology, it has high photographic sensitivity, forgiving exposure tolerance latitude, low fog-density, high contrast , high visibility of details and rich information. Under the same image quality conditions, this film greatly reducing the harm of rays.
Clear image quality
With bluish polyester base (blue image tone) and T-grain technology, it delivers excellent viewing characteristics, it makes the image of high sharpness, good resolution and rich image details, improved the image contrast and practical clarity.
Excellent process ability
This film is suitable for manual or automatic processing in standard and rapid (60 second ) cycles. It is applicable to various film processing chemicals. The processing tolerance is larger and the consumption of chemicals is less. With robust processing characteristics, it delivers consistent image quality in situations where there may be variations in chemistry temperature and chemistry integrity.
This film is suitable for various X-ray machine (including automatic machine) and photography to each part of human body. When it is operated incorrectly, it won't produce white artifact and it can improve the quality of the diagnosis.
Usage
The film should be handled carefully by the edges to avoid physical strains.
The best conditions of usage should be: temperature:18-24 ,humidity :50%RH-65%RH.
Hands must be clean, dry and free of lotions ,etc.
Safelight
Use a safelight filter (dark red) in a suitable safelight lamp equipped with a 15-watt bulb. Keep the film at least 4 feet (1.2
meters) from the safelight, and the total lighting time is in 10 minutes..
Film Processing
This film is designed for 90-seconds automated processing or manual processing.
The former is recommended with any kinds of film processor, developing at 30-35 in 23s.
In manual processing ,the film should be developed in temperature 20 for 5 minutes, fixed in 5-8 minutes, washed for 10-30 minutes and dried.
Usage of the Intensifying Screen
Can be matched with green sensitive intensifying screen.
Storage
Store in a cool, dry place (The suitable temperature is 10-20, the humidity is 30%RH-60%RH). Keep it away from dampness, high
temperature, any bad effective gases, x-ray, gamma ray or any other penetrating rays.
Stored vertically to avoid any harmful effect caused by pressure
| Product | Size | Inner Box | Outer Carton |
| Green/Blue Sensitive x-ray film | 18×24cm | 100pcs/box | 5boxes |
| 18×43cm | 100pcs/box | 5boxes | |
| 24×30cm | 100pcs/box | 5boxes | |
| 30×40cm | 100pcs/box | 5boxes | |
| 35×35cm | 100pcs/box | 5boxes | |
| 35×43cm | 100pcs/box | 5boxes | |
| 5in x 7in, 8in x 10in, 10in x 12in, 11in x 14in, 12in x 15in, Special specifications available according to customers' requirements. | |||
